7 - Inventory

Ansible

Linux

This is me documenting my journey of learning Ansible that is focused on network engineering. It’s not a “how-to guide” per-say, more of a diary. Each part will build upon the last. A lot of information on here is so I can come back to and reference later. I also learn best when teaching someone, and this is kind of me teaching.

Ansible Inventory

This part is where the inventory becomes a proper, production-quality data source with well-structured groups, realistic per-device variables, and platform-specific connection settings.

What an Inventory File Is

Before Ansible can do anything, it needs to know three things about each device: where it is (IP or hostname), how to connect to it (SSH credentials, connection type), and what kind of device it is (IOS, NX-OS, PAN-OS). The inventory file is where all of this lives.

Every ansible-playbook command references an inventory either explicitly with -i inventory/hosts.yml or implicitly through the inventory = setting in ansible.cfg. Without an inventory, Ansible has nothing to act on.

The inventory also defines groups, logical collections of hosts that I can target in playbooks. Instead of writing a playbook that names every device individually, I write hosts: cisco_ios and Ansible runs it against every device in the cisco_ios group. Add a new router to the group and the playbook automatically covers it.

What Lives in the Inventory vs. What Lives in Playbooks

This is a distinction worth being deliberate about from the start:

Belongs in Inventory	Belongs in Playbooks
Device hostnames and IPs	What tasks to run
Connection credentials	Which modules to use
Platform/OS type	Task logic and conditions
Device-specific variables (interfaces, VLANs)	Templates and configurations
Group membership	Error handling
Environment (lab, staging, prod)	Roles and includes

The inventory is the ‘what exists and how to reach it’. Playbooks are the ‘what to do’. Keeping these concerns separate makes both easier to maintain.

INI vs YAML Inventory Formats

Ansible supports multiple inventory file formats. The two most common are INI and YAML. I’ll show both side by side so I understand what I’m looking at when I encounter either in the wild, then commit to YAML for this lab.

The Same Inventory in Both Formats

INI Format:

# inventory/hosts.ini

[wan]
wan-r1 ansible_host=172.16.0.11
wan-r2 ansible_host=172.16.0.12

[spine_switches]
spine-01 ansible_host=172.16.0.21
spine-02 ansible_host=172.16.0.22

[leaf_switches]
leaf-01 ansible_host=172.16.0.23
leaf-02 ansible_host=172.16.0.24

[paloalto]
fw-01 ansible_host=172.16.0.10

[linux_hosts]
host-01 ansible_host=172.16.0.31
host-02 ansible_host=172.16.0.32

# Group of groups - cisco_ios contains the wan group
[cisco_ios:children]
wan

# Group of groups - cisco_nxos contains spine and leaf groups
[cisco_nxos:children]
spine_switches
leaf_switches

# Group of groups - datacenter contains nxos switches
[datacenter:children]
cisco_nxos

# Group-level variables (can also go in group_vars/ directory)
[cisco_ios:vars]
ansible_network_os=cisco.ios.ios
ansible_connection=network_cli

[cisco_nxos:vars]
ansible_network_os=cisco.nxos.nxos
ansible_connection=network_cli

[all:vars]
ansible_user=ansible
ansible_password=ansible123

YAML Format (equivalent):

# inventory/hosts.yml
---
all:
  children:
    cisco_ios:
      children:
        wan:
          hosts:
            wan-r1:
              ansible_host: 172.16.0.11
            wan-r2:
              ansible_host: 172.16.0.12
      vars:
        ansible_network_os: cisco.ios.ios
        ansible_connection: network_cli

    cisco_nxos:
      children:
        spine_switches:
          hosts:
            spine-01:
              ansible_host: 172.16.0.21
            spine-02:
              ansible_host: 172.16.0.22
        leaf_switches:
          hosts:
            leaf-01:
              ansible_host: 172.16.0.23
            leaf-02:
              ansible_host: 172.16.0.24
      vars:
        ansible_network_os: cisco.nxos.nxos
        ansible_connection: network_cli

    paloalto:
      hosts:
        fw-01:
          ansible_host: 172.16.0.10

    linux_hosts:
      hosts:
        host-01:
          ansible_host: 172.16.0.31
        host-02:
          ansible_host: 172.16.0.32

  vars:
    ansible_user: ansible
    ansible_password: ansible123

Comparison

Feature	INI	YAML
Readability for small inventories	Simpler, less indentation	More verbose
Readability for large/nested inventories	Gets messy fast	Hierarchical structure is clear
Group of groups	Requires `[group:children]` syntax	Native nesting
Variables per host	Inline on same line	Can be inline or in `host_vars/`
Works with dynamic inventory	INI plugins are deprecated	Standard format
Jinja2 and complex values	Limited	Full support
Recommended for	Quick one-off tests	All real projects

This Project

I use YAML exclusively for all projects. The INI format is fine for a five-device quick test but breaks down as inventory grows. YAML’s nested structure maps naturally to how I think about network hierarchy (core vs access, datacenter vs WAN, production vs lab).

The rest of this project uses YAML inventory.

Tip

When I find an old INI-format inventory and want to convert it to YAML, I can use ansible-inventory to do the conversion:

ansible-inventory -i old_inventory.ini --list -y > inventory/hosts.yml

The -y flag outputs in YAML format. I always review the output because automatic conversion sometimes flattens nested group structures that need to be manually reorganized.

Static Inventory

Part 6’s inventory was a starting point. Now I build it out properly with full group hierarchy, logical groupings, and a structure that mirrors how I’ll actually target devices in playbooks.

The Expanded `inventory/hosts.yml`

nano ~/projects/ansible-network/inventory/hosts.yml

---
# =============================================================
# Ansible Inventory — Enterprise Lab
# Containerlab Management Network: 172.16.0.0/24
#
# Group Hierarchy:
#   all
#   ├── network_devices
#   │   ├── cisco_ios        (WAN routers)
#   │   │   └── wan
#   │   ├── cisco_nxos       (DC switches)
#   │   │   ├── spine_switches
#   │   │   └── leaf_switches
#   │   └── paloalto         (Firewall)
#   └── linux_hosts          (End hosts)
#
# Logical Groups (cross-platform targeting):
#   ├── wan                  (WAN-facing devices)
#   ├── datacenter           (All DC devices)
#   └── edge                 (Firewall + WAN routers)
# =============================================================

all:
  children:

    # =========================================================
    # PLATFORM GROUPS
    # =========================================================

    cisco_ios:
      children:
        wan:
          hosts:
            wan-r1:
              ansible_host: 172.16.0.11
            wan-r2:
              ansible_host: 172.16.0.12

    cisco_nxos:
      children:
        spine_switches:
          hosts:
            spine-01:
              ansible_host: 172.16.0.21
            spine-02:
              ansible_host: 172.16.0.22
        leaf_switches:
          hosts:
            leaf-01:
              ansible_host: 172.16.0.23
            leaf-02:
              ansible_host: 172.16.0.24

    paloalto:
      hosts:
        fw-01:
          ansible_host: 172.16.0.10

    linux_hosts:
      hosts:
        host-01:
          ansible_host: 172.16.0.31
        host-02:
          ansible_host: 172.16.0.32

    # =========================================================
    # LOGICAL GROUPS
    # =========================================================

    # All devices involved in WAN connectivity
    wan_edge:
      hosts:
        wan-r1:
        wan-r2:
        fw-01:

    # All datacenter switching infrastructure
    datacenter:
      children:
        spine_switches:
        leaf_switches:

    # All network devices
    network_devices:
      children:
        cisco_ios:
        cisco_nxos:
        paloalto:

Understanding Group Hierarchy

When a device belongs to a group, it also implicitly belongs to all parent groups above it. For example, spine-01 is in:

spine-01
  └── spine_switches      (direct parent)
      └── cisco_nxos      (grandparent)
          └── network_devices  (great-grandparent)
              └── all          (top-level — always exists)

This matters for variable inheritance and for playbook targeting. If I write hosts: cisco_nxos, my playbook runs against spine-01, spine-02, leaf-01, and leaf-02. All devices in the hierarchy beneath cisco_nxos.

Targeting Devices in Playbooks

The group structure I’ve built gives me flexible targeting:

Target all Cisco IOS devices (wan-r1, wan-r2)

hosts: cisco_ios

Target only spine switches

hosts: spine_switches

Target all NX-OS devices (all 4 switches)

hosts: cisco_nxos

Target all network devices (everything except Linux hosts)

hosts: network_devices

Target a single device

hosts: wan-r1

Target multiple specific groups

hosts: spine_switches,leaf_switches

Target all devices EXCEPT Linux hosts

hosts: all,!linux_hosts

Target WAN edge devices only

hosts: wan_edge

Tip

The ! operator excludes a group. hosts: all,!linux_hosts means every device in all except those in linux_hosts.

Host Variables

Host variables are variables specific to a single device. Ansible has a set of magic variables, special variable names it recognizes and uses to control connection behavior.

The Essential Connection Variables

Variable	Purpose	Example Value
`ansible_host`	The IP or hostname Ansible connects to	`172.16.0.11`
`ansible_port`	SSH port (default: 22)	`22`
`ansible_user`	SSH username	`ansible`
`ansible_password`	SSH password (use Vault in production)	`ansible123`
`ansible_network_os`	Platform identifier for network_cli	`cisco.ios.ios`
`ansible_connection`	Connection plugin to use	`network_cli`
`ansible_become`	Enable privilege escalation	`true`
`ansible_become_method`	How to escalate (enable, sudo)	`enable`
`ansible_become_password`	Enable/sudo password	`ansible123`
`ansible_ssh_private_key_file`	Path to SSH private key	`~/.ssh/lab_key`
`ansible_ssh_common_args`	Extra SSH arguments	`-o StrictHostKeyChecking=no`
`ansible_httpapi_use_ssl`	Use HTTPS for httpapi connection	`true`
`ansible_httpapi_validate_certs`	Validate SSL certificates	`false`
`ansible_persistent_connect_timeout`	Timeout for persistent connection	`30`
`ansible_command_timeout`	Timeout per command	`30`

Where to Set Variables

Host variables can be set in three places:

Inline in hosts.yml - on the same line/block as the host definition
In host_vars/<hostname>.yml - a dedicated file per device
In group_vars/<groupname>.yml - shared across all devices in a group

The rule I follow:

If a variable is the same for every device in a group → group_vars/
If a variable is unique to a single device → host_vars/<hostname>.yml
If a variable is truly global (same for every device everywhere) → group_vars/all.yml
Never put credentials inline in hosts.yml - they should always be in group_vars/ or host_vars/ where Vault can encrypt them

Group Variables

The group_vars/ directory is where I define variables that apply to an entire group. Ansible automatically reads these files when it processes the inventory.

Directory Structure

inventory/
├── hosts.yml
├── group_vars/
│   ├── all.yml              # Applies to every device
│   ├── cisco_ios.yml        # Applies to all cisco_ios hosts
│   ├── cisco_nxos.yml       # Applies to all cisco_nxos hosts
│   ├── paloalto.yml         # Applies to all paloalto hosts
│   ├── spine_switches.yml   # Applies to spine switches only
│   ├── leaf_switches.yml    # Applies to leaf switches only
│   ├── wan.yml              # Applies to WAN group only
│   └── linux_hosts.yml      # Applies to Linux hosts
└── host_vars/
    ├── wan-r1.yml
    ├── wan-r2.yml
    ├── spine-01.yml
    └── ...

Global Variables

nano ~/projects/ansible-network/inventory/group_vars/all.yml

---
# =============================================================
# Global variables
# =============================================================

# --- Credentials ---
ansible_user: ansible
ansible_password: "ansible123"

# --- NTP Servers ---
ntp_servers:
  - 216.239.35.0
  - 216.239.35.4

# --- DNS Servers ---
dns_servers:
  - 8.8.8.8
  - 8.8.4.4

# --- Syslog Server ---
syslog_server: 172.16.0.100

# --- Domain Name ---
domain_name: lab.local

# --- SNMP Community ---
snmp_community_ro: "lab-read-only"

# --- Default SSH timeout settings ---
ansible_persistent_connect_timeout: 30
ansible_command_timeout: 30

IOS-XE Connection Settings

nano ~/projects/ansible-network/inventory/group_vars/cisco_ios.yml

---
# =============================================================
# Cisco IOS / IOS-XE
# =============================================================

ansible_network_os: cisco.ios.ios
ansible_connection: network_cli

# Privilege escalation
ansible_become: true
ansible_become_method: enable
ansible_become_password: "ansible123"

# --- IOS-specific platform settings ---
# Prevent line wrapping in show commands
ansible_terminal_length: 0

# --- IOS Feature Flags ---
ios_resource_modules_supported: true

# --- Backup settings ---
backup_dir: backups/cisco_ios

NX-OS Connection Settings

nano ~/projects/ansible-network/inventory/group_vars/cisco_nxos.yml

---
# =============================================================
# Cisco NX-OS
# =============================================================

ansible_network_os: cisco.nxos.nxos
ansible_connection: network_cli

# NX-OS does not use enable mode
ansible_become: false

# --- NX-OS specific settings ---
# Terminal width setting for NX-OS
ansible_terminal_length: 0

# --- NX-OS Features to ensure are enabled ---
nxos_features_required:
  - bgp
  - ospf
  - interface-vlan
  - lacp
  - lldp
  - vpc
  - nxapi

# --- Backup settings ---
backup_dir: backups/cisco_nxos

Spine-Specific Variables

nano ~/projects/ansible-network/inventory/group_vars/spine_switches.yml

---
# =============================================================
# Spine Switches - DC spine layer specific variables
# =============================================================

# Role identifier
device_role: spine

# BGP AS number for spine layer
bgp_as: 65000

# Spine-to-spine link subnet
spine_interconnect_subnet: "10.0.0.0/30"

# Loopback interface for BGP router-id and overlay
loopback_interface: "Loopback0"

# MTU for fabric links (jumbo frames for VXLAN)
fabric_mtu: 9216

Leaf-Specific Variables

nano ~/projects/ansible-network/inventory/group_vars/leaf_switches.yml

---
# =============================================================
# Leaf Switches - DC leaf layer specific variables
# =============================================================

device_role: leaf

# VLANs that all leaf switches should have
base_vlans:
  - id: 10
    name: MGMT
    subnet: "192.168.10.0/24"
  - id: 20
    name: APP_SERVERS
    subnet: "192.168.20.0/24"
  - id: 30
    name: DB_SERVERS
    subnet: "192.168.30.0/24"
  - id: 99
    name: NATIVE
    subnet: ""

# SVI (Layer 3 VLAN interface) settings
svi_enabled: true

# VPC domain settings (for dual-homed servers)
vpc_keepalive_vlan: 4094

PAN-OS Connection Settings

nano ~/projects/ansible-network/inventory/group_vars/paloalto.yml

---
# =============================================================
# Palo Alto PAN-OS - Connection and platform settings
# =============================================================

ansible_network_os: paloaltonetworks.panos.panos
ansible_connection: ansible.netcommon.httpapi
ansible_httpapi_use_ssl: true
ansible_httpapi_validate_certs: false

# PAN-OS API port
ansible_port: 443

# --- PAN-OS specific settings ---
panos_device_group: "lab"

# Vsys to target
panos_vsys: "vsys1"

# Backup settings
backup_dir: backups/paloalto

# Security zone names
zones:
  untrust: "untrust"
  trust: "trust"
  dmz: "dmz"

WAN Group Variables

nano ~/projects/ansible-network/inventory/group_vars/wan.yml

---
# =============================================================
# WAN Group - Variables for WAN-facing routers
# =============================================================

device_role: wan_router

# BGP AS for WAN routers
bgp_as: 65100

# OSPF process ID for WAN routing
ospf_process_id: 1
ospf_area: 0

# WAN interface naming convention
wan_interface: GigabitEthernet1

Linux Host Connection Settings

nano ~/projects/ansible-network/inventory/group_vars/linux_hosts.yml

---
# =============================================================
# Linux Hosts — Alpine Linux containers
# =============================================================

ansible_connection: ssh
ansible_python_interpreter: /usr/bin/python3

# Default shell
ansible_shell_type: sh

device_role: server

Tip

When a host belongs to multiple groups (e.g., spine-01 belongs to both spine_switches and cisco_nxos), it inherits variables from all of them. If the same variable is defined in multiple group files, Ansible resolves the conflict using ‘variable precedence’’ which means more specific groups win over less specific ones. host_vars/ always wins over group_vars/.

Host Variables

While group_vars/ handles settings shared across a group, host_vars/ is for variables that are unique to a specific device such as its loopback IP, its BGP AS number, its specific interface assignments.

Directory Structure

mkdir -p ~/projects/ansible-network/inventory/host_vars/{wan-r1,wan-r2,fw-01,spine-01,spine-02,leaf-01,leaf-02,host-01,host-02}

IOS-XE WAN Router

nano ~/projects/ansible-network/inventory/host_vars/wan-r1.yml

---
# =============================================================
# wan-r1 — Cisco IOS-XE WAN Router 1
# Management IP: 172.16.0.11
# Role: Primary WAN router, BGP to upstream ISP
# =============================================================

# --- Device Identity ---
device_hostname: wan-r1
device_role: wan_router
device_vendor: cisco
device_platform: ios-xe
device_location: HQ-DC-Rack-A1
device_serial: LAB-SERIAL-001

# --- Management ---
ansible_host: 172.16.0.11

# --- Loopback Interface ---
loopback0:
  ip: 10.255.0.1
  mask: 255.255.255.255
  description: "Loopback0 | Router-ID"

# --- WAN Interface ---
interfaces:
  GigabitEthernet1:
    description: "WAN | To FW-01 eth1"
    ip: 10.10.10.1
    mask: 255.255.255.252
    state: up
  GigabitEthernet2:
    description: "WAN | To WAN-R2 (inter-router link)"
    ip: 10.10.20.1
    mask: 255.255.255.252
    state: up

# --- Routing ---
ospf_router_id: 10.255.0.1
ospf_area: 0
ospf_interfaces:
  - GigabitEthernet1
  - GigabitEthernet2
  - Loopback0

bgp_as: 65100
bgp_router_id: 10.255.0.1
bgp_neighbors:
  - neighbor_ip: 10.10.10.2
    remote_as: 65200
    description: "eBGP to FW-01"

# --- ACLs ---
acls:
  - name: MGMT_ACCESS
    type: standard
    entries:
      - sequence: 10
        action: permit
        source: 172.16.0.0
        wildcard: 0.0.0.255
      - sequence: 20
        action: deny
        source: any

# --- NTP ---
ntp_source_interface: Loopback0

# --- SNMP ---
snmp_location: "HQ-DC-Rack-A1-U12"
snmp_contact: "[email protected]"

IOS-XE WAN Router 2

nano ~/projects/ansible-network/inventory/host_vars/wan-r2.yml

---
# =============================================================
# wan-r2 — Cisco IOS-XE WAN Router 2
# Management IP: 172.16.0.12
# Role: Secondary WAN router, BGP redundancy
# =============================================================

device_hostname: wan-r2
device_role: wan_router
device_vendor: cisco
device_platform: ios-xe
device_location: HQ-DC-Rack-A2
device_serial: LAB-SERIAL-002

ansible_host: 172.16.0.12

loopback0:
  ip: 10.255.0.2
  mask: 255.255.255.255
  description: "Loopback0 | Router-ID"

interfaces:
  GigabitEthernet1:
    description: "WAN | To FW-01 eth2"
    ip: 10.10.11.1
    mask: 255.255.255.252
    state: up
  GigabitEthernet2:
    description: "WAN | To WAN-R1 (inter-router link)"
    ip: 10.10.20.2
    mask: 255.255.255.252
    state: up

ospf_router_id: 10.255.0.2
ospf_area: 0
ospf_interfaces:
  - GigabitEthernet1
  - GigabitEthernet2
  - Loopback0

bgp_as: 65100
bgp_router_id: 10.255.0.2
bgp_neighbors:
  - neighbor_ip: 10.10.11.2
    remote_as: 65200
    description: "eBGP to FW-01"

snmp_location: "HQ-DC-Rack-A2-U12"
snmp_contact: "[email protected]"

Palo Alto PAN-OS Firewall

nano ~/projects/ansible-network/inventory/host_vars/fw-01.yml

---
# =============================================================
# fw-01 — Palo Alto PAN-OS Firewall
# Management IP: 172.16.0.10
# Role: WAN edge firewall, security policy enforcement
# =============================================================

device_hostname: fw-01
device_role: firewall
device_vendor: paloalto
device_platform: pan-os
device_location: HQ-DC-Rack-A3
device_serial: LAB-SERIAL-003

ansible_host: 172.16.0.10

# --- Security Zones ---
security_zones:
  - name: untrust
    mode: layer3
    interfaces:
      - ethernet1/1
      - ethernet1/2
  - name: trust
    mode: layer3
    interfaces:
      - ethernet1/3
      - ethernet1/4
  - name: mgmt
    mode: layer3
    interfaces: []

# --- Interfaces ---
interfaces:
  ethernet1/1:
    description: "Untrust | To WAN-R1"
    ip: 10.10.10.2
    mask: 255.255.255.252
    zone: untrust
  ethernet1/2:
    description: "Untrust | To WAN-R2"
    ip: 10.10.11.2
    mask: 255.255.255.252
    zone: untrust
  ethernet1/3:
    description: "Trust | To SPINE-01"
    ip: 10.20.0.1
    mask: 255.255.255.252
    zone: trust
  ethernet1/4:
    description: "Trust | To SPINE-02"
    ip: 10.20.0.5
    mask: 255.255.255.252
    zone: trust

# --- Address Objects ---
address_objects:
  - name: RFC1918-10
    type: ip-netmask
    value: 10.0.0.0/8
  - name: RFC1918-172
    type: ip-netmask
    value: 172.16.0.0/12
  - name: RFC1918-192
    type: ip-netmask
    value: 192.168.0.0/16
  - name: DC-SERVERS
    type: ip-netmask
    value: 192.168.20.0/24

# --- BGP ---
bgp_as: 65200
bgp_router_id: 10.255.0.10

snmp_location: "HQ-DC-Rack-A3-U10"
snmp_contact: "[email protected]"

NX-OS Spine Switch 1

nano ~/projects/ansible-network/inventory/host_vars/spine-01.yml

---
# =============================================================
# spine-01 — Cisco NX-OS Spine Switch 1
# Management IP: 172.16.0.21
# Role: DC spine, BGP route reflector, VXLAN VTEP
# =============================================================

device_hostname: spine-01
device_role: spine
device_vendor: cisco
device_platform: nxos
device_location: HQ-DC-Rack-B1
device_serial: LAB-SERIAL-021

ansible_host: 172.16.0.21

# --- Loopback ---
loopback0:
  ip: 10.255.1.1
  mask: 255.255.255.255
  description: "Loopback0 | Router-ID"

loopback1:
  ip: 10.255.2.1
  mask: 255.255.255.255
  description: "Loopback1 | VTEP NVE source"

# --- Fabric Interfaces ---
interfaces:
  Ethernet1/1:
    description: "Fabric | To FW-01 eth3"
    ip: 10.20.0.2
    mask: 255.255.255.252
    mtu: 9216
    state: up
  Ethernet1/2:
    description: "Fabric | To SPINE-02 (inter-spine)"
    ip: 10.20.1.1
    mask: 255.255.255.252
    mtu: 9216
    state: up
  Ethernet1/3:
    description: "Fabric | To LEAF-01"
    ip: 10.20.2.1
    mask: 255.255.255.252
    mtu: 9216
    state: up
  Ethernet1/4:
    description: "Fabric | To LEAF-02"
    ip: 10.20.3.1
    mask: 255.255.255.252
    mtu: 9216
    state: up

# --- BGP ---
bgp_as: 65000
bgp_router_id: 10.255.1.1
bgp_neighbors:
  - neighbor_ip: 10.20.0.1
    remote_as: 65200
    description: "eBGP to FW-01"
  - neighbor_ip: 10.20.2.2
    remote_as: 65001
    description: "eBGP to LEAF-01"
  - neighbor_ip: 10.20.3.2
    remote_as: 65002
    description: "eBGP to LEAF-02"

# --- NX-OS VPC Domain ---
vpc_domain_id: 1
vpc_peer_ip: 172.16.0.22

snmp_location: "HQ-DC-Rack-B1-U20"
snmp_contact: "[email protected]"

NX-OS Leaf Switch 1

nano ~/projects/ansible-network/inventory/host_vars/leaf-01.yml

---
# =============================================================
# leaf-01 — Cisco NX-OS Leaf Switch 1
# Management IP: 172.16.0.23
# Role: DC access layer, server connectivity, VPC peer
# =============================================================

device_hostname: leaf-01
device_role: leaf
device_vendor: cisco
device_platform: nxos
device_location: HQ-DC-Rack-C1
device_serial: LAB-SERIAL-023

ansible_host: 172.16.0.23

loopback0:
  ip: 10.255.1.3
  mask: 255.255.255.255
  description: "Loopback0 | Router-ID"

# --- Fabric uplinks ---
interfaces:
  Ethernet1/1:
    description: "Fabric | To SPINE-01"
    ip: 10.20.2.2
    mask: 255.255.255.252
    mtu: 9216
    state: up
  Ethernet1/2:
    description: "Fabric | To SPINE-02"
    ip: 10.20.4.2
    mask: 255.255.255.252
    mtu: 9216
    state: up
  Ethernet1/3:
    description: "Access | To HOST-01"
    mode: access
    access_vlan: 20
    state: up

# --- BGP ---
bgp_as: 65001
bgp_router_id: 10.255.1.3
bgp_neighbors:
  - neighbor_ip: 10.20.2.1
    remote_as: 65000
    description: "eBGP to SPINE-01"
  - neighbor_ip: 10.20.4.1
    remote_as: 65000
    description: "eBGP to SPINE-02"

# --- VLANs specific to this leaf ---
local_vlans:
  - id: 20
    name: APP_SERVERS
  - id: 30
    name: DB_SERVERS

# --- VPC ---
vpc_domain_id: 10
vpc_peer_ip: 172.16.0.24

snmp_location: "HQ-DC-Rack-C1-U18"
snmp_contact: "[email protected]"

Variable Precedence Preview

Since I now have variables defined in group_vars/all.yml, group_vars/cisco_ios.yml, group_vars/wan.yml, and host_vars/wan-r1.yml, I need to understand which one wins when the same variable is defined in multiple places.

The rule is simple: more specific always wins.

host_vars/wan-r1.yml         ← Highest priority (most specific)
    ↑
group_vars/wan.yml           ← More specific group
    ↑
group_vars/cisco_ios.yml     ← Less specific group (parent)
    ↑
group_vars/all.yml           ← Lowest priority (applies to everything)

A practical example: ansible_become_password is set in group_vars/cisco_ios.yml as ansible123. If wan-r1 has a different enable password (common in real networks where devices have unique credentials), I override it in host_vars/wan-r1.yml:

# host_vars/wan-r1.yml
ansible_become_password: "unique-enable-password-for-r1"

This overrides the group-level setting for wan-r1 only. All other IOS devices still use the group setting. Full variable precedence is covered in depth in Part 11.

Dynamic Inventory

So far I’ve been maintaining a static inventory, a YAML file I update manually whenever a device is added, removed, or changed. This works fine for a lab with 9 devices. It doesn’t work for an enterprise with 500 devices changing constantly.

Dynamic inventory solves this by generating the inventory automatically from an external source of truth. Typically a CMDB, IPAM, or network management platform. Instead of a static YAML file, I provide a dynamic inventory plugin that queries the source of truth at runtime and returns a live inventory.

How Dynamic Inventory Works

ansible-playbook site.yml -i inventory/
         │
         ▼
Ansible sees inventory/ directory
         │
         ├── hosts.yml         ← Static hosts (if any)
         └── netbox.yml        ← Dynamic inventory plugin config
                  │
                  ▼
         Plugin queries Netbox API
                  │
                  ▼
         Returns host list + variables
                  │
                  ▼
         Ansible merges static + dynamic inventory
         and proceeds with playbook execution

The key insight: from a playbook’s perspective, there’s no difference between a statically-defined host and a dynamically-discovered one. Both show up the same way. The difference is only in how the inventory is maintained.

The Netbox Dynamic Inventory Plugin

Netbox is the industry-standard network source of truth. When Netbox is running, I replace (or supplement) my static hosts.yml with a Netbox inventory plugin config.

Here’s what that config file looks like (I’m creating it now even though Netbox isn’t running yet) so the structure is familiar when I get to it:

nano ~/projects/ansible-network/inventory/netbox.yml

---
# =============================================================
# Netbox Dynamic Inventory Plugin Configuration
# This file will be active once Netbox is set up in Part 26
# For now, comment out the plugin line to prevent errors
# =============================================================

# Uncomment when Netbox is running:
# plugin: netbox.netbox.nb_inventory

plugin: netbox.netbox.nb_inventory

# --- Netbox Connection ---
api_endpoint: http://192.168.1.100:8000    # Replace with actual Netbox IP
token: "{{ lookup('env', 'NETBOX_TOKEN') }}"    # Token from environment variable
validate_certs: false                           # Lab — self-signed cert

# --- What to pull from Netbox ---
# Pull devices (not virtual machines) into the inventory
compose:
  ansible_host: primary_ip4.address | ipaddr('address')

# --- Grouping ---
# Create Ansible groups based on Netbox attributes
group_by:
  - device_roles
  - platforms
  - sites
  - tags

# --- Filters ---
# Only pull active devices
device_query_filters:
  - status: active

# Only pull devices that have a primary IP set
# (devices without IPs can't be automated)
filters:
  has_primary_ip: true

# --- Variable mapping ---
# Map Netbox fields to Ansible variables
compose:
  ansible_network_os: >-
    {
      'cisco-ios-xe': 'cisco.ios.ios',
      'cisco-nxos': 'cisco.nxos.nxos',
      'panos': 'paloaltonetworks.panos.panos'
    }[platform.slug] | default('unknown')
  device_role: device_role.slug
  site_name: site.name
  rack: rack.name | default('unknown')

What this configuration does when active:

Connects to the Netbox API and pulls all active devices that have a primary IP
Creates Ansible groups automatically based on device role, platform, site, and tags defined in Netbox
Maps Netbox’s platform slugs to Ansible’s ansible_network_os values
Pulls device-specific data (rack, site, role) as Ansible variables automatically

Info

The token: "{{ lookup('env', 'NETBOX_TOKEN') }}" syntax reads the API token from an environment variable rather than hardcoding it in the file. The config file goes in Git, the token stays out of Git. I set the environment variable before running Ansible: export NETBOX_TOKEN=my_token_here. This can also be stored in a .env file (which is in .gitignore) and sourced before running playbooks.

Static vs Dynamic

Scenario	Use
Lab environment with fixed devices	Static (`hosts.yml`)
Production with 50+ devices	Dynamic (Netbox plugin)
Devices change frequently (cloud, SDN)	Dynamic
No source of truth system available	Static
Mixed environment (some in Netbox, some not)	Both — Ansible merges them
CI/CD pipeline where inventory must be deterministic	Static (pinned)

For this lab, I use static inventory through Part 25. Part 26 migrates to Netbox dynamic inventory.

Testing the Inventory

With the full inventory built out, I validate it thoroughly before running any playbooks against it.

`ansible-inventory --graph`

The graph view shows the group hierarchy visually:

cd ~/projects/ansible-network
ansible-inventory -i inventory/ --graph

Expected output:

@all:
  |--@cisco_ios:
  |  |--@wan:
  |  |  |--wan-r1
  |  |  |--wan-r2
  |--@cisco_nxos:
  |  |--@spine_switches:
  |  |  |--spine-01
  |  |  |--spine-02
  |  |--@leaf_switches:
  |  |  |--leaf-01
  |  |  |--leaf-02
  |--@paloalto:
  |  |--fw-01
  |--@linux_hosts:
  |  |--host-01
  |  |--host-02
  |--@wan_edge:
  |  |--wan-r1
  |  |--wan-r2
  |  |--fw-01
  |--@datacenter:
  |  |--spine-01
  |  |--spine-02
  |  |--leaf-01
  |  |--leaf-02
  |--@network_devices:
  |  |--wan-r1
  |  |--wan-r2
  |  |--fw-01
  |  |--spine-01
  |  |--spine-02
  |  |--leaf-01
  |  |--leaf-02
  |--@ungrouped:

`ansible-inventory --list`

The list view shows the full inventory as JSON including all variables:

ansible-inventory -i inventory/ --list

This is verbose but useful for confirming that variables from group_vars and host_vars are being read correctly.

`ansible-inventory --host <hostname>`

Shows all variables that apply to a specific host — including inherited group variables:

ansible-inventory -i inventory/ --host wan-r1

Expected output:

{
    "ansible_become": true,
    "ansible_become_method": "enable",
    "ansible_become_password": "ansible123",
    "ansible_command_timeout": 30,
    "ansible_connection": "network_cli",
    "ansible_host": "172.16.0.11",
    "ansible_network_os": "cisco.ios.ios",
    "ansible_password": "ansible123",
    "ansible_persistent_connect_timeout": 30,
    "ansible_user": "ansible",
    "backup_dir": "backups/cisco_ios",
    "bgp_as": 65100,
    "bgp_neighbors": [...],
    "device_hostname": "wan-r1",
    "device_location": "HQ-DC-Rack-A1",
    "device_role": "wan_router",
    "dns_servers": ["8.8.8.8", "8.8.4.4"],
    "domain_name": "lab.local",
    "interfaces": {...},
    "loopback0": {...},
    "ntp_servers": ["216.239.35.0", "216.239.35.4"],
    "ospf_area": 0,
    ...
}

This output shows exactly what variables Ansible will have available when running a task against wan-r1. If a variable is missing here, it won’t be available in playbooks or templates.

Tip

I run ansible-inventory --host <device> whenever a playbook fails with an undefined variable error. It immediately shows whether the variable exists in the inventory at all, and if so, what value it has. This is faster than grep-ing through multiple group_vars and host_vars files manually.

Testing Connectivity Against the Inventory

With the lab running, I test that Ansible can actually reach all devices:

Test all IOS-XE devices

ansible cisco_ios -i inventory/ -m ansible.netcommon.net_ping

Test all NX-OS devices

ansible cisco_nxos -i inventory/ -m ansible.netcommon.net_ping

Test all network devices at once

ansible network_devices -i inventory/ -m ansible.netcommon.net_ping

Test Linux hosts

ansible linux_hosts -i inventory/ -m ansible.builtin.ping

Limiting to Specific Hosts During Testing

Run against a single host

ansible cisco_ios -i inventory/ -m ansible.netcommon.net_ping --limit wan-r1

Run against a pattern

ansible all -i inventory/ -m ansible.netcommon.net_ping --limit "spine*"

Run against everything except one device

ansible all -i inventory/ -m ansible.netcommon.net_ping --limit "all,!fw-01"

Committing the Expanded Inventory to Git

cd ~/projects/ansible-network

git add inventory/
git status

git commit -m "feat(inventory): expand inventory with full group_vars and host_vars

- Add comprehensive group_vars for all platforms (cisco_ios, cisco_nxos,
  paloalto, linux_hosts, spine_switches, leaf_switches, wan, all)
- Add realistic host_vars for all 9 lab devices with interface data,
  routing parameters, BGP AS numbers, and device metadata
- Add logical group structure (wan_edge, datacenter, network_devices)
- Add Netbox dynamic inventory config (inactive until Part 26)
- Expand hosts.yml with full group hierarchy and comments"

The inventory is now a proper data source.

Last updated on March 13, 2026 • Ernesto Diaz

7 - Inventory

Ansible Inventory

What an Inventory File Is

What Lives in the Inventory vs. What Lives in Playbooks

INI vs YAML Inventory Formats

The Same Inventory in Both Formats

Comparison

This Project

Static Inventory

The Expanded inventory/hosts.yml

Understanding Group Hierarchy

Targeting Devices in Playbooks

Host Variables

The Essential Connection Variables

Where to Set Variables

Group Variables

Directory Structure

Global Variables

IOS-XE Connection Settings

NX-OS Connection Settings

Spine-Specific Variables

Leaf-Specific Variables

PAN-OS Connection Settings

WAN Group Variables

Linux Host Connection Settings

Host Variables

Directory Structure

IOS-XE WAN Router

IOS-XE WAN Router 2

Palo Alto PAN-OS Firewall

NX-OS Spine Switch 1

NX-OS Leaf Switch 1

Variable Precedence Preview

Dynamic Inventory

How Dynamic Inventory Works

The Netbox Dynamic Inventory Plugin

Static vs Dynamic

Testing the Inventory

ansible-inventory --graph

ansible-inventory --list

ansible-inventory --host <hostname>

Testing Connectivity Against the Inventory

Limiting to Specific Hosts During Testing

Committing the Expanded Inventory to Git

The Expanded `inventory/hosts.yml`

`ansible-inventory --graph`

`ansible-inventory --list`

`ansible-inventory --host <hostname>`
